Custom Electric Pallet Truck Manufacturers, Suppliers

Electric Pallet Truck

Electric pallet Truck suitable for short-distance transportation, battery power saves labor costs and is more efficient and convenient.

EPS steering system lessens the steering force, increasing the sensitivity, and improving the performance of steering reversal,so the vehicle slows down automatically on the curve and is easy and safe to operate.
ACmotorof vertical drive with no carbon brush, having better stability on the ramp plus regenerative braking, which effectively increases work efficiency and service duration of electric motor plus more energy-saving.
Configured with ZAPI controller, ALBRIGHT contactor, and water-proof AMP connector assembly of power supply.
With peculiar technology of shock absorption of drive, which enables the traffic-ability more
Two oil cylinders are equipped to implement the synchronized lifting function, additionally cutting off the power supply automatically at the top lifting height.
Driven on a stand-up platform with shock absorption.

MODEL				HC120	HC125	HC130
Performance	Maximum load capacity		kg	2000	2500	3000
	load center	Q	mm	600	600	600
	Maximum lifting height	H3	mm	120	120	120
	Travel speed(without load		km/h	5.5	5.5	5.5
	Travel speed(with load		km/h	5	5	5
	Lifting speed (without load)		mm/s	50	50	50
	Lifting speed (with load)		mm/s	30	30	30
	Lowering speed (without load)		mm/s	57	57	57
	Lowering speed (with load)		mm/s	57	57	57
	Gradeablity (without load)		%	7	7	7
	Gradeablity(with load)		%	6	6	5
	Service Weight (with battery		kg	685	685	585
Dimension	Overall length of frame	L	mm	1775	1775	1775
	Overall length of frame(with platform)		mm	2280	2280	2280
	Overall width of frame	B	mm	735	735	735
	Whoelbas	Y	mm	1417	1417	1417
	Fork length		mm	1150	1150	1150
	Fork outside width	B1	mm	685	685	685
	Forkinside width	B2	mm	345	345	345
	Fork thicknes5		mm	60	60	60
	Fork height when fork lowered to lowes	s	mm	85	85	85
	Min ground clearance		mm	5	5	5
	The theoretical width of the aisle for right-angle stacking(1200×10000	Asts	mm	2312	2312	2312
	Minimumtuming radius (without platform)	Wa	mm	1625	1625	1625
	Minimumtuming radius (with platform)	Wa1	mm	2135	2135	2135
Tire	Front-wheel		mm	85*70	85*70	85*70
	Drive wheel		mm	230*75	230*75	230*75
	Caster wheel		mm	130*55	130*55	130*55
	Wheel material		polyurethane
Electrical components	Drive motor type	AC series motor
	Rated output		kw	1.5	1.5	1.5
	Host motor type	DC series motor
	Rated output		kw	0.8	1.2	1.2
	Voltage		V		24
battery	Capacity		AH		210
battery	Weight		kg		195

Industry knowledge

Electric pallet truck: Hecha Intelligent Equipment Co., Ltd.'s efficient logistics solution, how does it help companies optimize short-distance transportation?

In today's rapidly developing logistics industry, efficient and convenient transportation equipment has become a key factor for companies to improve operational efficiency. Hecha Intelligent Equipment Co., Ltd., as a leader in the field of electric pallet trucks, is gradually changing the face of traditional logistics operations with its advanced technology and rich product lines. This article will explore in depth how the electric pallet trucks provided by Hecha Intelligent Equipment Co., Ltd. are an ideal choice for companies to optimize short-distance transportation, and introduce the versatility of the company's other logistics equipment to meet the needs of different scenarios.

Electric pallet truck: an efficient artifact for short-distance transportation
Electric pallet trucks are based on battery power. Compared with traditional human or internal combustion engine-driven equipment, they significantly reduce labor costs and improve operating efficiency. This type of vehicle is particularly suitable for short-distance and high-frequency transportation tasks in warehouses, factories, supermarkets and other places. The electric pallet trucks of Hecha Intelligent Equipment Co., Ltd. are exquisitely designed and easy to operate. They not only reduce the labor intensity of personnel, but also achieve more precise handling operations through intelligent control systems, ensuring the safety and integrity of goods.

Battery power: environmentally friendly and energy-saving, continuous and efficient
Electric pallet trucks use high-performance batteries as power sources, which not only reduces carbon emissions and conforms to the green logistics concept of modern enterprises, but also has lower maintenance costs and less noise than internal combustion engine vehicles, making them more suitable for use in indoor environments. Hecha's electric pallet trucks are equipped with an efficient battery management system that can be quickly charged, extend the single operation time, and ensure efficient operation around the clock.

Multifunctional product line: meeting the needs of different scenarios
In addition to electric pallet trucks, Hecha Intelligent Equipment Co., Ltd. also provides comprehensive logistics equipment solutions, including internal combustion counterbalanced forklifts, battery counterbalanced forklifts, electric logistics handling equipment, etc. These products can be equipped with a variety of functional modules according to customer needs, such as side shifting, rotation, telescopic and other functions, to flexibly cope with various complex terrains and operating environments. Whether it is stacking operations in narrow passages or loading and unloading tasks in wide warehouses, Hecha can provide the most suitable solutions to help customers achieve efficient and intelligent logistics operations.

Customer customized services: create exclusive logistics solutions
Hecha Intelligent Equipment Co., Ltd. is well aware that the logistics needs of each enterprise are unique, so the company provides professional customized services. From demand analysis, solution design to equipment installation and commissioning, every step strives to accurately meet customer needs and ensure that the logistics equipment provided can maximize customer operational efficiency and reduce costs.

With the continuous upgrading of the logistics industry, electric pallet trucks and their supporting equipment have become an important force in promoting the modernization of logistics. Hecha Intelligent Equipment Co., Ltd. is leading the industry towards a more efficient, environmentally friendly and intelligent direction with its leading electric pallet truck technology and comprehensive logistics equipment product line. For companies seeking to optimize short-distance transportation and improve logistics efficiency, choosing Hecha is undoubtedly a wise decision.
